LAT CENTRE no. 060 - ACCREDITATION TABLE
UNIT TEMPERATURE
THERMOMETRIC CHAINS - INDICATORS AND TRANSMITTERS
SENSOR (IMMERSION)
MEASUREMENT RANGE [°C]
UNCERTAINTY [°C] (*)
THERMORESISTORS -80/250
250/600
NOBLE METAL THERMOCOUPLES -80/50
50/250
250/550
550/1100
COMMON METAL THERMOCOUPLES/THERMISTORS -80/50
50/250
250/550
550/1100
(*)

Measurement uncertainties are expressed as twice the standard deviation (corresponding, in the case of normal distribution, to a confidence level of 95%)
Uris indicates type uncertainty due to instrument resolution
